Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	40A15		Bulb, Light (40 Watt)   (Replaces: A0282803)			Immediately	$ 1.98
2	D7653003		Breaker, Ref Top V		Appelez-nous	-
3	B8322902		Block Evap. Coil		Appelez-nous	-
4	B8361701		Block Evap Coil		Appelez-nous	-
5	B8345401		Gasket, Damper		Appelez-nous	-
6	W11384469		Switch   (Replaces: C3680304)			Immediately	$ 39.09
7	C8842505		Center Mullion, Almond		Appelez-nous	-
7	C8842501		W Center Mull. -pnt		Appelez-nous	-
9	C8902601		Insert, Control		Appelez-nous	-
10	C8907302		Cold Control Fzr		Appelez-nous	-
11	D7009802		Knob		Appelez-nous	-
12	D7543201		Insulation Damper		Appelez-nous	-
13	D7545009		Control Cover		Appelez-nous	-
14	D7547402		Damper Control, Warm 26.5°f, N		Appelez-nous	-
15	D7654504		Heater, Mullion		Appelez-nous	-
16	D7714708		Bottom, Freezer		Appelez-nous	-
17	WP2264462		Grommet   (Replaces: A1017202)			Immediately	$ 46.17
18	C8881301		Brkt Evap Fan		Appelez-nous	-
19	WPC8891605		Motor, Evap Fan   (Replaces: C8891601)				$ 344.82
20	C8927801		Blade, Evap Fan		Appelez-nous	-
21	D7524501		Brkt Evap Fan Shroud		Appelez-nous	-
22	WP489464		Screw   (Replaces: M0211217)			Immediately	$ 8.38
23	B5733302		Clip, Ground		Appelez-nous	-
24	D7714401		Socket-light		Appelez-nous	-
25	C8730101		Shield, Light		Appelez-nous	-
27	C8887904		Insul. Dr Block		Appelez-nous	-
28	D7816904		Drain Block Kit		Appelez-nous	-
29	D7539312		Top Ref.		Appelez-nous	-
30	D7649602		Harness Mullion		Appelez-nous	-
31	67006425		Screw   (Replaces: M0230917)			Immediately	$ 7.30
32	M0275117		Tape Per Roll A		Appelez-nous	-
33	B5757703		Gasket, Air Block		Appelez-nous	-
34	B5757808		Gasket		Appelez-nous	-
35	R9800670		Kit, Screw   (Replaces: M0257244)				$ 10.58
36	D7713802		Bracket, Control		Appelez-nous	-
37	M0234003		Screw		Appelez-nous	-
39	M0350101		Switch		Appelez-nous	-
40	D7874601		Evap Cover		Appelez-nous	-
42	A3189320		Gasket, Foam		Appelez-nous	-
44	WP10442411		Thermostat, Defrost   (Replaces: C8978402)			Immediately	$ 44.02
45	D7549703		Heater Evap.		Appelez-nous	-
46	D7759001		Heat Exchanger		Appelez-nous	-
47	C8952001		Clip		Appelez-nous	-
48	R0170033		Evaporator Assembly		Appelez-nous	-
49	A3253803		Clamp		Appelez-nous	-
50	D7864401		Harness Liner		Appelez-nous	-
51	WP98165		Screw, Sm   (Replaces: M0211018)				$ 8.57
52	67006425		Screw-sm No.8-1/2lg   (Replaces: M0211017)			Immediately	$ 7.30
54	876370		Insulation, Batt   (Replaces: B0523561)				$ 243.14
55	D7691102		Shroud Fan		Appelez-nous	-
56	C8932201		Barrier Lt-sw K		Appelez-nous	-
57	WPW10339879		Tie   (Replaces: M0321202)				$ 8.30
58	R9800670		Kit, Screw   (Replaces: M0211030)				$ 10.58
59	M0216531		Screw		Appelez-nous	-
61	D7501301		Drip Tray Evaporator		Appelez-nous	-
62	B8335701		Tube, Drip Tray		Appelez-nous	-
63	M0353916		Screw		Appelez-nous	-
64	A3263906		Gasket-per Ft		Appelez-nous	-
65	A3138301		Grommet		Appelez-nous	-
