Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	WP681414		Screw, 10-16 X 1/2 (2)   (Replaces: 343641)			Immediately	$ 8.47
1	330191		Latch Assembly (pyro)		Appelez-nous	-
2	98106		Screw (2)		Appelez-nous	-
2	1N4004		Safety Switch   (Replaces: 313309)		Appelez-nous	-
3	309245		Insulator, Switch		Appelez-nous	-
4	309258		Screw,6-3/8 (2)		Appelez-nous	-
4	313035		Shield, Latch Terminal		Appelez-nous	-
5	311056		Screw (2)		Appelez-nous	-
5	WP488627		Screw, 8a X 1/2   (Replaces: 338156)				$ 8.11
5	308422		Screw, 10-24 X 1/2 (2)		Appelez-nous	-
5	307976		Handle, Latch		Appelez-nous	-
6	307977		Knob, Latch		Appelez-nous	-
7	307929		Burner Box		Appelez-nous	-
7	WP3390631		Screw, 10a X 3/8 (4)   (Replaces: 309112)				$ 8.25
8	307973		Shield, Wiring		Appelez-nous	-
8	WP681414		Screw, 10-16 X 1/2 (4)   (Replaces: 343641)			Immediately	$ 8.47
9	WP681414		Screw, 10-32 X 1/2 (ground)   (Replaces: 690989)			Immediately	$ 8.47
9	307968		Rod, Cooktop		Appelez-nous	-
10	307967		Retainer, Cooktop		Appelez-nous	-
10	WP3390631		Screw, 10a X 3/8   (Replaces: 309112)				$ 8.25
11	307965		Bracket, Cooktop (2)		Appelez-nous	-
11	WP681414		Screw, 10-16 X 1/2 (4)   (Replaces: 343641)			Immediately	$ 8.47
12	307966		Pin, Cooktop (2)		Appelez-nous	-
12	WP681414		Screw, 10-16 X 1/2 (4)   (Replaces: 343641)			Immediately	$ 8.47
13	313165		Cooktop (toast)		Appelez-nous	-
13	313166		Cooktop (platinum)		Appelez-nous	-
13	WP681414		Cooktop (screw 10-32 X 1/2)   (Replaces: 690989)			Immediately	$ 8.47
13	307871		Cooktop (almond)		Appelez-nous	-
13	307863		Cooktop (harvest Gold)		Appelez-nous	-
13	307864		Cooktop (coffee)		Appelez-nous	-
13	307865		Cooktop (new Avocado)		Appelez-nous	-
13	307866		Cooktop (white)		Appelez-nous	-
14	330031		Clip, Mtg. (4)   (Replaces: 3147829)			Immediately	$ 16.09
15	WP308605		Strain, Relief   (Replaces: 308605)				$ 11.76
15	WP681414		Screw,10-16 X 1/2   (Replaces: 343641)			Immediately	$ 8.47
16	330031		Receptacle (4) (service Unit Service Replacement)			Immediately	$ 16.09
16	WP313808		Screw 6-32 X 1/4 (4)   (Replaces: 311932)				$ 8.30
17	W10854470		Adapter Ring 6`` (2)   (Replaces: 306785)				$ 94.93
17	W10858781		Adapter Ring 8`` (2)   (Replaces: 306786)				$ 99.92
18	W10291024		Reflector Pan 6`` (2)   (Replaces: 306789)			Immediately	$ 55.44
18	W10291024		Reflector Pan (8`` (2))   (Replaces: 306790)			Immediately	$ 55.44
19	WP660532		Unit, Surface (2) (6``) (240v) (alt.) L.f. & R.r.   (Replaces: 309334)			Immediately	$ 41.00
19	WP660532		Unit, Surface (2) (6``) (240v) (alt.)   (Replaces: 313964)			Immediately	$ 41.00
19	WP660532		Unit, Surface (2) (6``) (240v)   (Replaces: 660532)			Immediately	$ 41.00
20	309195		Medallion (4)		Appelez-nous	-
21	686608		Connector (2)		Appelez-nous	-
22	307748		Screw, 10a X 1/2		Appelez-nous	-
22	312320		Shield, Insulation		Appelez-nous	-
25	WP681414		Screw, 10-16 X 1/2 (4)   (Replaces: 343641)			Immediately	$ 8.47
25	313716		Shield, Heat (2)		Appelez-nous	-
	WP660533		Unit, Surface (2) (8``) (240v)   (Replaces: 660533)			Immediately	$ 43.86
	WP660533		(alt.)   (Replaces: 313963)			Immediately	$ 43.86
	WP660533		(alt.) R.f. & L.r. (includes Illus. 20)   (Replaces: 309340)			Immediately	$ 43.86
