SELECT A DIAGRAM

01 - Cooktop, Literature


02 - Control Panel


03 - Manifold


04 - Chassis


05 - Broiler


06 - Door, Optional


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	LIT8273166		Literature (instructions, Installation)		Appelez-nous	-
1	LIT3195945		Literature (installation, Instructions (template))		Appelez-nous	-
1	LIT8522717		Guide, Use & Care		Appelez-nous	-
1	LIT8053556		Literature (tech Sheet)		Appelez-nous	-
1	LIT3191638		Safer Cooking Tips		Appelez-nous	-
2	WP3191903		Cap, Burner (lf, Lr, Rf) (grey)   (Replaces: 3191903)				$ 191.50
2	WP3191898		Cap, Burner (rr) (black)   (Replaces: 3191898)				$ 71.00
2	3191899		Cap, Burner (rr) (grey)				$ 31.21
2	WP3191901		Cap, Burner (lf, Lr, Rf) (black)   (Replaces: 3191901)				$ 128.91
4	8273216		Burner (rr)		Appelez-nous	-
4	WP4455980		Burner (lf, Lr, Rf)   (Replaces: 8273215)				$ 65.21
5	8272251		Cooktop (white)		Appelez-nous	-
6	WP8523854		Panel, Manifold (white)   (Replaces: 8273025)				$ 290.58
6	8523855		Panel, Manifold (black)   (Replaces: 8273027)				$ 176.18
7	WP8273103		Knob, Control (4) (black)   (Replaces: 8273103)			Immediately	$ 16.85
7	WP8273104		Knob, Control (4) (white)   (Replaces: 8273104)			Immediately	$ 17.99
8	8053391		Grate, Burner (4) (grey)				$ 242.28
8	WPW10268483		Grate, Burner (4) (black)   (Replaces: 8053458)				$ 140.02
10	3195813		Clip, Cooktop (2)		Appelez-nous	-
12	WP3195060		Hinge, Cooktop (2)   (Replaces: 3195060)			Immediately	$ 13.18
13	W11233072		Screw   (Replaces: 3196178)			Immediately	$ 14.72
14	WP3368921		Screw   (Replaces: 3400701)			Immediately	$ 8.56
15	WP3196557		Screw   (Replaces: 3196557)			Immediately	$ 7.95

    View Diagram in Separate Window       Print Part List
