SELECT A DIAGRAM

1 - Freezer Door


2 - Fresh Food Door


3 - Freezer Section


4 - Freezer Shelves


5 - Ice Maker & Dispenser


6 - Fresh Food Section


7 - Fresh Food Shelves


8 - Sealed System & Mother Board


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
5	WR02X10431		Dart Clip		Appelez-nous	-
6	WR12X10388		Tail Handle Sxs Wh		Appelez-nous	-
7	WR12X10332		Handle Sxs Wh		Appelez-nous	-
17	WR02X11430		Plate Door Stop Ff		Appelez-nous	-
18	WG03L01095		Cam & Thimble Ff   (Replaces: WR02X11479)				$ 6.09
103	WR24X10128		Gasket Door Ff		Appelez-nous	-
106	WR01L14045		Door Dairy   (Replaces: WR22X10012)				$ 22.93
109	WR71X10232		Shelf Module Fixed Ff		Appelez-nous	-
115	WG03L00204		Shelf Module Ff   (Replaces: WR71X10231)				$ 77.88
121	WG03L01961		Tail Handle Sxs Wh   (Replaces: WR12X10389)				$ 58.06
128	WR01L04421		Snugger Module   (Replaces: WR02X10582)			Immediately	$ 31.76
152	WR01X10596		Scr 8-18 Ab Fltr 5/8 S		Appelez-nous	-
181	WR01X10655		Scr 10-32 F Hxw 3/4 S		Appelez-nous	-
910	WR78X10662		Door Asm Foam Ff Wh		Appelez-nous	-
911	WR01X10201		Thimble Top Closed		Appelez-nous	-

    View Diagram in Separate Window       Print Part List
