1 - Component Group
2 - Magnetron & Power Supply Parts
New Model Search:
| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | WB62X1496 | Cooktop - Fa |
|
- | |||||
| 1 | WB62X1498 | Cooktop Ad |
|
- | |||||
| 1 | WB62X1494 | Cooktop Wh |
|
- | |||||
| 1 | WZ04X0231 | Screw Mt. Side |
|
- | |||||
| 1 | WB62X1495 | Cooktop - Cf |
|
- | |||||
| 1 | WB62X1497 | Cooktop Ha |
|
- | |||||
| 2 | WB7X971 | Trim Cooktop |
|
- | |||||
| 3 | WB2X2988 | Clip Trim |
|
- | |||||
| 3 | WS01A01150 | Screw (cr) (Replaces: WB1X5364) |
|
$ 3.97 | |||||
| 4 | WB2X6498 | Post Asm Rh |
|
- | |||||
| 4 | WZ04X0231 | Screw Mt. Side |
|
- | |||||
| 4 | WB2X6499 | Post Asm Lh |
|
- | |||||
| 5 | WB2X2984 | Bracket End Cap Rh |
|
- | |||||
| 5 | WZ04X0231 | Screw Mt. Side |
|
- | |||||
| 5 | WB2X2985 | Bracket End Cap Lh |
|
- | |||||
| 6 | WZ04X0231 | Screw Mt. Side |
|
- | |||||
| 6 | WB7X969 | Trim Side Rh |
|
- | |||||
| 6 | WB7X970 | Trim Side Lh |
|
- | |||||
| 7 | WB7X6701 | End Cap Rh |
|
- | |||||
| 7 | WB7X6702 | End Cap Lh |
|
- | |||||
| 8 | WB1X5520 | Speednut |
|
- | |||||
| 8 | WB7X6677 | End Cap Lh |
|
- | |||||
| 8 | WZ04X0384 | Screw Mtg End Cap |
|
- | |||||
| 8 | WB7X6676 | End Cap Rh |
|
- | |||||
| 9 | WB2X6241 | Plate Shield |
|
- | |||||
| 10 | WB7X5503 | Shield Latch Handle |
|
- | |||||
| 11 | WB7X6703 | Deflector |
|
- | |||||
| 11 | WZ06X0038 | Scr 8-18 Ab Hxw 5/8 S |
|
- | |||||
| 12 | WB7X6704 | Cover Top |
|
- | |||||
| 12 | WZ04X0231 | Screw Mt. Side |
|
- | |||||
| 13 | WB7X6705 | Trim Cover |
|
- | |||||
| 14 | WZ04X0349 | Screw |
|
- | |||||
| 14 | WB2X6578 | Bracket Cover |
|
- | |||||
| 15 | WZ04X0231 | Screw Mt. Side |
|
- | |||||
| 15 | WB49X298 | Guard Wire |
|
- | |||||
| 15 | WB2X6609 | Clamp Harness |
|
- | |||||
| 16 | WB7X967 | Trim Lower |
|
- | |||||
| 16 | WZ05X0187 | Scr 8-32 T Ovr 1/2 S |
|
- | |||||
| 17 | WB2X6880 | Bracket Instrument |
|
- | |||||
| 18 | WB2X3232 | Pad |
|
- | |||||
| 18 | WB36X5442 | Crystal |
|
- | |||||
| 18 | WB36X5417 | Crystal, Control (01) |
|
- | |||||
| 19 | WB2X1608 | Neon Lamp 118v |
|
$ 31.65 | |||||
| 20 | WB2X2979 | Clip Lamp |
|
- | |||||
| 21 | WB2X1608 | Neon Lamp 118v |
|
$ 31.65 | |||||
| 22 | WZ02X0528 | Scr 8-32 M Phr 3/16 S |
|
- | |||||
| 22 | WB24X231 | Thermo Asm Dual Range |
|
- | |||||
| 22 | WB2X6274 | Sleeve Cap Tube |
|
- | |||||
| 23 | WB3X493 | Knob Thermostat |
|
- | |||||
| 24 | WB22X5090 | Switch, Oven |
|
- | |||||
| 24 | WZ02X0528 | Scr 8-32 M Phr 3/16 S |
|
- | |||||
| 25 | WB3X479 | Knob Oven Switch |
|
- | |||||
| 26 | WB1X540 | Nut |
|
- | |||||
| 26 | WB19M160CP | Timer Digital (Replaces: WB19X5231) |
|
- | |||||
| 27 | WB2X3231 | Bracket Timer |
|
- | |||||
| 27 | WZ04X0304 | Screw Mt. Duct |
|
- | |||||
| 28 | WB3X459 | Knob Timer |
|
- | |||||
| 29 | WB2X6881 | Bracket Instrument |
|
- | |||||
| 30 | WB2X6882 | Bracket Front Frame |
|
- | |||||
| 31 | WB1X542 | Speednut |
|
- | |||||
| 32 | WB2X6883 | Resistor - Board Assm. |
|
- | |||||
| 32 | WB2X6494 | Barrier |
|
- | |||||
| 32 | WZ04X0232 | Scr 8-18 Ab Hxs 3/8 S |
|
- | |||||
| 33 | WB1X588 | Lockwasher Switch |
|
- | |||||
| 33 | WB24X218 | Switch, Latch Release |
|
- | |||||
| 34 | WB1X5517 | Trim Switch |
|
- | |||||
| 35 | WB2X1608 | Neon Lamp 118v |
|
$ 31.65 | |||||
| 36 | WB19X5255 | Timer |
|
- | |||||
| 36 | WZ02X0529 | Screw |
|
- | |||||
| 37 | WB4X5072 | Dial Timer |
|
- | |||||
| 38 | WB25X5039 | Pointer Time & Temp |
|
- | |||||
| 39 | WB3X5603 | Knob, Timer, Microwave |
|
- | |||||
| 40 | WB2X6884 | Barrier |
|
- | |||||
| 40 | WB2X6917 | Bracket, Support Potenti |
|
- | |||||
| 40 | WB1X443 | Nut |
|
- | |||||
| 40 | WB24X5147 | Potentiometer & Lead Asm |
|
- | |||||
| 40 | WB24X5132 | Potentiometer - Lead Asm |
|
- | |||||
| 42 | WB3X5595 | Knob |
|
- | |||||
| 42 | WB3X5614 | Knob Variable Power |
|
- | |||||
| 43 | WB2X1608 | Neon Lamp 118v |
|
$ 31.65 | |||||
| 44 | WB2X6494 | Barrier |
|
- | |||||
| 44 | WZ02X0528 | Scr 8-32 M Phr 3/16 S |
|
- | |||||
| 44 | WB21X239 | Switch, Inf Surface Unit |
|
- | |||||
| 45 | WB3X480 | Knob Surface Unit |
|
- | |||||
| 46 | WB49X5226 | Cover Back |
|
- | |||||
| 47 | WB25X5052 | Dial Indicator |
|
- | |||||
| 100 | WB1X5355 | Screw Recept Terminal |
|
- | |||||
| 100 | PS240M | Surface Unit, 8" (Replaces: WB30X219) |
|
Immediately | $ 44.95 | ||||
| 101 | WB32X51 | Center Trim 8" Unit |
|
- | |||||
| 102 | WB31X5011 | Pan Ring 8" Chrome |
|
- | |||||
| 103 | WB30X218 | Surface Unit, 6" |
|
- | |||||
| 103 | WB1X5355 | Screw Recept Terminal |
|
- | |||||
| 104 | WB31X5010 | Pan Ring 6" Chrome |
|
- | |||||
| 105 | WB32X52 | Center Trim 6" Unit |
|
- | |||||
| 106 | WB17X5051 | Receptacle Asm |
|
- | |||||
| 106 | WB5X5026 | Spring Contact Pkg |
|
- | |||||
| 107 | WB2X6171 | Insulator |
|
- | |||||
| 108 | WB2X6172 | Clip Insulator |
|
- | |||||
| 150 | WB2X6609 | Clamp Harness |
|
- | |||||
| 151 | WB56X5840 | Frame Front |
|
- | |||||
| 151 | WZ04X0413 | Screw |
|
- | |||||
| 151 | WB2X3240 | Spacer |
|
- | |||||
| 152 | WB2X6913 | Panel Filler |
|
- | |||||
| 152 | WZ04X0231 | Screw Mt. Side |
|
- | |||||
| 153 | WB49X5149 | Box Cooktop |
|
- | |||||
| 153 | WZ04X0231 | Screw Mt. Side |
|
- | |||||
| 153 | WB2X3238 | Pad |
|
- | |||||
| 153 | WB2X6906 | Deflector Vent |
|
- | |||||
| 153 | WB2X6914 | Bracket Vent |
|
- | |||||
| 154 | WB38X5039 | Body Vent |
|
- | |||||
| 155 | WB63X239 | Guard Top Insulation |
|
- | |||||
| 155 | WS01A01150 | Screw (cr) (Replaces: WB1X5364) |
|
$ 3.97 | |||||
| 156 | WB49X5221 | Guard Upper Rh |
|
- | |||||
| 156 | WB49X5222 | Guard Upper Lh |
|
- | |||||
| 157 | WB49X5220 | Guard Lower |
|
- | |||||
| 158 | WB2X6187 | Support Oven |
|
- | |||||
| 159 | WB17X168 | Terminal Block-power |
|
- | |||||
| 159 | WB2X646 | Plate Ground |
|
- | |||||
| 159 | WZ04X0348 | Scr 10-16 B Sl 1-1/8 S |
|
- | |||||
| 160 | WB17X167 | Block Term Distribution |
|
- | |||||
| 160 | WZ04X0384 | Screw Mtg End Cap |
|
- | |||||
| 161 | WS01A02255 | Screw (Replaces: WB1X536) |
|
$ 3.97 | |||||
| 161 | WB2X6191 | Bracket Knockout |
|
- | |||||
| 162 | WZ04X0304 | Screw Mt. Duct |
|
- | |||||
| 162 | WB2X6655 | Cover Terminal Block |
|
- | |||||
| 163 | WZ04X0231 | Screw Mt. Side |
|
- | |||||
| 163 | WB2X6873 | Cover, Fan |
|
- | |||||
| 164 | WB49X5225 | Cover Back |
|
- | |||||
| 164 | WZ04X0231 | Screw Mt. Side |
|
- | |||||
| 165 | WB1X5516 | Leveling Leg |
|
- | |||||
| 166 | WB10X5125 | Support Hinge Rh |
|
- | |||||
| 166 | WB1X5497 | Scr 10-16 Ab Ihw 1/2 S |
|
- | |||||
| 166 | WB10X5126 | Support Hinge Lh |
|
- | |||||
| 166 | WB1X5471 | Scr 8-18 Ab T 15/32 S |
|
- | |||||
| 167 | WB10X5127 | Hinge Lever Rh & Lh |
|
- | |||||
| 169 | WB1X5509 | Screw, Mtg. Trans. |
|
- | |||||
| 170 | WZ10X0016 | Washer |
|
- | |||||
| 171 | WG02A00596 | Pin Hinge Door (Replaces: WB2X6195) |
|
$ 4.20 | |||||
| 172 | WB2X1082 | Ring Retaining |
|
- | |||||
| 173 | WB2X2506 | Hook Door Spring |
|
- | |||||
| 174 | WB9X5076 | Spring Door |
|
- | |||||
| 175 | WB2X6342 | Guide Hinge Lever |
|
- | |||||
| 176 | WB2X6929 | Barrier, Sw. |
|
- | |||||
| 176 | WB27X85 | Switch Latch |
|
- | |||||
| 176 | WZ05X0234 | Screw Mt Switch |
|
- | |||||
| 177 | WB2X3085 | Plate Guide |
|
- | |||||
| 178 | WB2X3084 | Bracket Switch |
|
- | |||||
| 179 | WB2X3105 | Barrier |
|
- | |||||
| 179 | WB1X555 | Speednut |
|
- | |||||
| 180 | WZ04X0231 | Screw Mt. Side |
|
- | |||||
| 180 | WB2X6831 | Clip False |
|
- | |||||
| 181 | WB2X3018 | Clip Lead |
|
- | |||||
| 182 | WB2X6875 | Bracket |
|
- | |||||
| 182 | WZ04X0231 | Screw Mt. Side |
|
- | |||||
| 183 | WB56X5842 | Panel Fa |
|
- | |||||
| 183 | WB56X5835 | Drawer Panel Wh |
|
- | |||||
| 183 | WB56X5841 | Panel Cf |
|
- | |||||
| 183 | WB56X5837 | Drawer Panel Ad |
|
- | |||||
| 183 | WB56X5836 | Drawer Panel Ha |
|
- | |||||
| 183 | WB2X6930 | Grommet Strip |
|
- | |||||
| 184 | WB2X6931 | Bracket, Mtg. Clip |
|
- | |||||
| 225 | WB14X5034 | Latch |
|
- | |||||
| 225 | WZ02X0546 | Scr 8-32 M Phr 1/2 S |
|
- | |||||
| 226 | WB1X438 | Screw Washer Asm |
|
- | |||||
| 226 | WB15X5127 | Handle Latch |
|
- | |||||
| 227 | WB3X322 | Knob Latch |
|
- | |||||
| 228 | WG02A00753 | Retainer Knob (Replaces: WB2X2030) |
|
$ 4.20 | |||||
| 229 | WZ04X0421 | Screw Mtg. Channel To La |
|
- | |||||
| 229 | WB2X6892 | Channel Latch |
|
- | |||||
| 230 | WB2X6891 | Bar Slide |
|
- | |||||
| 231 | WB2X6905 | Lever Lock |
|
- | |||||
| 232 | WB2X6844 | Pin Cotter |
|
- | |||||
| 233 | WB9X5087 | Spring |
|
- | |||||
| 234 | WB24X131 | Switch |
|
- | |||||
| 235 | WB1X428 | Screw |
|
- | |||||
| 236 | WB24X187 | Solenoid |
|
- | |||||
| 236 | WZ04X0374 | Scr 10-32 Tt Hxw 1/4 S |
|
- | |||||
| 237 | WB2X3102 | Bracket Lock |
|
- | |||||
| 237 | WZ04X0289 | Scr 8-18 Ab Hx 1/4 S |
|
- | |||||
| 237 | WS01A02255 | Screw (Replaces: WB1X536) |
|
$ 3.97 | |||||
| 238 | WB2X6212 | Pivot Stud |
|
- | |||||
| 239 | WB2X1800 | Retainer Ring |
|
- | |||||
| 240 | WB2X6871 | Actuator Bar Latch |
|
- | |||||
| 241 | WB1X5535 | Screw |
|
- | |||||
| 242 | WB14X36 | Latch Assembly |
|
- | |||||
| 242 | WZ02X0546 | Scr 8-32 M Phr 1/2 S |
|
- | |||||
| 243 | WZ05X0234 | Screw Mt Switch |
|
- | |||||
| 243 | WB2X6889 | Barrier Switch |
|
- | |||||
| 243 | WB27X85 | Switch Latch |
|
- | |||||
| 244 | WZ04X0421 | Screw Mtg. Channel To La |
|
- | |||||
| 244 | WB2X6887 | Bracket Switch |
|
- | |||||
| 245 | WB2X6888 | Support Handle |
|
- | |||||
| 245 | WB1X438 | Screw Washer Asm |
|
- | |||||
| 246 | WB2X6890 | Bracket Actuator |
|
- | |||||
| 300 | WB2X1222 | Pad Glass (felt) |
|
- | |||||
| 300 | WB36X554 | Glass Black |
|
- | |||||
| 301 | WB56X5678 | Panel Door |
|
- | |||||
| 302 | WB7X5625 | Trim Door |
|
- | |||||
| 302 | WZ04X0231 | Screw Mt. Side |
|
- | |||||
| 303 | WB2X6573 | Pad Trim |
|
- | |||||
| 304 | WB2X6574 | Clip-trim Door |
|
- | |||||
| 305 | WB2X6575 | Clip Trim |
|
- | |||||
| 306 | WB7X5629 | Trim Door |
|
- | |||||
| 307 | WB7X5631 | Cap Trim |
|
- | |||||
| 308 | WB7X5630 | Trim Top |
|
- | |||||
| 309 | WB2X3053 | Clip Mtg Door Trims |
|
- | |||||
| 310 | WZ04X0231 | Screw Mt. Side |
|
- | |||||
| 310 | WB55X5219 | Guard Insulation |
|
- | |||||
| 311 | WB2X6546 | Insulation Door |
|
- | |||||
| 312 | WB55X5233 | Door Liner |
|
- | |||||
| 313 | WB55X5234 | Panel Inner |
|
- | |||||
| 314 | WB1X537 | Screw |
|
- | |||||
| 314 | WB2X7027 | Gasket, Door |
|
- | |||||
| 315 | WB9X5088 | Spring Strike |
|
- | |||||
| 315 | WZ04X0304 | Screw Mt. Duct |
|
- | |||||
| 316 | WB15X145 | Handle |
|
- | |||||
| 317 | WB2X6243 | Grommet Handle |
|
- | |||||
| 318 | WB2X6204 | Spacer Panel |
|
- | |||||
| 319 | WZ04X0298 | Screw Mtg Handle |
|
- | |||||
| 320 | WB1X119 | Washer Contoured |
|
- | |||||
| 321 | WB2X6270 | Spacer Door |
|
- | |||||
| 322 | WB1X558 | Screw Nail Point |
|
- | |||||
| 323 | WB1X5545 | Wisher Liner To Hinge Su |
|
- | |||||
| 323 | WB1X5538 | Scr 8-32 Th T 1-13/32 S |
|
- | |||||
| 350 | WB2X6874 | Insulation |
|
- | |||||
| 350 | WB53X5082 | Oven Liner |
|
- | |||||
| 351 | WB1X5536 | Scr 8-18 Ab T 13/32 S |
|
- | |||||
| 352 | WB2X6896 | Plate Mounting |
|
- | |||||
| 352 | WZ05X0165 | Screw Mtg Flange |
|
- | |||||
| 353 | WB2X6899 | Holder Thermal Switch |
|
- | |||||
| 354 | WB2X6898 | Holder Thermal Switch |
|
- | |||||
| 355 | WB2X6897 | Hanger Thermal Switch |
|
- | |||||
| 356 | WB24X175 | Switch, Thermal |
|
- | |||||
| 356 | WB2X6215 | Clamp Harness |
|
- | |||||
| 357 | WB2X6886 | Retainer Socket |
|
- | |||||
| 358 | WB8X5060 | Lampholder |
|
- | |||||
| 359 | WB1X5537 | Screw Mtg. Housing To Re |
|
- | |||||
| 359 | WB2X6885 | Housing Lamp |
|
- | |||||
| 361 | WB2X6867 | Hinge Lamp |
|
- | |||||
| 361 | WB1X5536 | Scr 8-18 Ab T 13/32 S |
|
- | |||||
| 362 | WZ04X0345 | Screw 8-18x5/8 Hxw |
|
- | |||||
| 362 | WB2X6868 | Trim Asm |
|
- | |||||
| 363 | WB36X5416 | Glass Oven Lamp |
|
- | |||||
| 364 | WB2X6872 | Gasket |
|
- | |||||
| 365 | WB49X88 | Broil Pan |
|
- | |||||
| 366 | WB48X5002 | Broiler Pan Rack |
|
- | |||||
| 367 | WB48X5059 | Rack (19 Bar) |
|
- | |||||
| 367 | WB48X5060 | Rack (11 Bar) |
|
- | |||||
| 368 | WB44X186 | Mullion Unit |
|
- | |||||
| 368 | WB2X3253 | Mullion Unit Clip |
|
- | |||||
| 369 | WB2X6916 | Gasket |
|
- | |||||
| 400 | WB1X500 | Terminal Screw |
|
- | |||||
| 400 | WB44X205 | Bake Unit 208/240v |
|
- | |||||
| 400 | WZ05X0165 | Screw Mtg Flange |
|
- | |||||
| 401 | WB2X2502 | Insulator |
|
- | |||||
| 402 | WZ10X0114 | Lockwasher |
|
- | |||||
| 403 | WZ02X0521 | Screw |
|
- | |||||
| 404 | WZ05X0165 | Screw Mtg Flange |
|
- | |||||
| 404 | WB1X500 | Terminal Screw |
|
- | |||||
| 404 | WB2X6895 | Support Capillary |
|
- | |||||
| 404 | WB44X204 | Broil Unit 208/240v |
|
- | |||||
| 405 | WZ05X0165 | Screw Mtg Flange |
|
- | |||||
| 405 | WB2X6894 | Bracket Broil |
|
- | |||||
| 425 | WB1X500 | Terminal Screw |
|
- | |||||
| 425 | WZ04X0345 | Screw 8-18x5/8 Hxw |
|
- | |||||
| 425 | WB29X5011 | Smoke Eliminator Asm |
|
- | |||||
| 426 | WB2X3388 | Terminal Block |
|
- | |||||
| 520 | WB17X5059 | Housing Socket Pkg 9 Pin |
|
- | |||||
| 520 | WB17X5062 | Terminal Blk Asm (12pin) |
|
- | |||||
| 520 | WB17X5061 | Terminal Blk Asm (3 Pin) |
|
- | |||||
| 520 | WB17X5060 | Terminal Blk Asm (2 Pin) |
|
- |
