1 - Component Group
2 - Magnetron & Power Supply Parts
New Model Search:
| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 500 | WB2X6876 | Pad |
|
- | |||||
| 500 | WB49X5261 | Panel, Power Supply |
|
- | |||||
| 503 | WB49X5223 | Pan, Bottom |
|
- | |||||
| 504 | WB2X7008 | Tray Component |
|
- | |||||
| 505 | WZ05X0184 | Screw Mtg. Relay |
|
- | |||||
| 505 | WB27X5159 | Relay Clean |
|
- | |||||
| 506 | WB27X5203 | Fuse Holder |
|
- | |||||
| 506 | WZ05X0184 | Screw Mtg. Block |
|
- | |||||
| 507 | CF15FB | Fuse (Replaces: WB27X7) |
|
Immediately | $ 3.63 | ||||
| 508 | WB27X5085 | Triac |
|
- | |||||
| 509 | WZ05X0184 | Screw Mtg. Triac |
|
- | |||||
| 509 | WB2X6829 | Brkt. Mtg. Triac |
|
- | |||||
| 510 | WB24X5130 | Circuit Board & Brkt. Asm. |
|
- | |||||
| 511 | WB27X5149 | Transformer |
|
- | |||||
| 512 | WB2X7512 | Barrier Terminals, Capacitor |
|
- | |||||
| 512 | WB27X5213 | Capacitor |
|
- | |||||
| 513 | WB2X6903 | Bracket Mtg. Capacitor |
|
- | |||||
| 514 | WB27X5096 | Transformer - Hi-voltage |
|
- | |||||
| 514 | WB2X6494 | Barrier |
|
- | |||||
| 514 | WZ06X0132 | Screw Mtg. Trans. |
|
- | |||||
| 515 | 11QBP0235 | Screw Mtg. Recrifier (Replaces: WB27X5070) |
|
$ 15.33 | |||||
| 515 | WZ04X0413 | Screw Mtg. Rectifier |
|
- | |||||
| 516 | WZ06X0132 | Screw Mtg. Blower Asm. |
|
- | |||||
| 516 | WB26X5057 | Motor |
|
- | |||||
| 517 | WB2X7009 | Bracket Mtg. Mtr.(2) |
|
- | |||||
| 517 | WZ05X0226 | Screw Mtg. Motor To Brkt. |
|
- | |||||
| 518 | WB2X7010 | Blade Motor |
|
- | |||||
| 519 | WB2X6215 | Clamp Wire |
|
- | |||||
| 520 | WB17X5059 | Terminal Block Pkg.(9 Pin) |
|
- | |||||
| 520 | WB17X5062 | Terminal Block Pkg.(12 Pin) |
|
- | |||||
| 520 | WB17X5060 | Terminal Block Pkg.(2 Pin) |
|
- | |||||
| 520 | WB17X5061 | Terminal Block Pkg.(3 Pin) |
|
- | |||||
| 521 | WB2X6879 | Support, Magnetron |
|
- | |||||
| 522 | WB27X5142 | Magnetron |
|
- | |||||
| 522 | WB1X5355 | Screw Mtg. Mag. To Supt. |
|
- | |||||
| 522 | WB2X7415 | Barrier Terminals Magnetron |
|
- | |||||
| 522 | WB18X5048 | Magnetron Hi-voltage Wire |
|
- | |||||
| 523 | WB27X5117 | Thermostat |
|
- | |||||
| 524 | WB2X6046 | Rf Gasket |
|
- | |||||
| 525 | WB26X5045 | Motor, Stirrer |
|
- | |||||
| 526 | WZ04X0304 | Screw Mtg. Motor |
|
- | |||||
| 526 | WB2X6893 | Bracket, Mtg. Motor |
|
- | |||||
| 527 | WB2X6866 | Stirrer Blade Asm. |
|
- | |||||
| 528 | WB2X6844 | Cotter Pin |
|
- | |||||
| 529 | WB49X5227 | Wave Guide |
|
- | |||||
| 530 | WB2X6877 | Gasket |
|
- | |||||
| 531 | WB2X6878 | Glass Plate |
|
- | |||||
| 532 | WB7X6706 | Flange - Glass Plate |
|
- | |||||
| 532 | WZ05X0165 | Screw |
|
- |
