1 - Freezer Door


2 - Fresh Food Door


3 - Freezer Section


4 - Freezer Shelves


5 - Ice Maker & Dispenser


6 - Fresh Food Section


7 - Fresh Food Shelves


8 - Sealed System & Mother Board


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
6	WR12X10203		Tail Handle Sxs Bk		Appelez-nous	-
7	WR12X10434		Handle Sxs Bk		Appelez-nous	-
17	WR02X10575		Plate Door Stop Ff Wh		Appelez-nous	-
18	WR02X10567		Hinge Cam & Thimble Ff		Appelez-nous	-
103	WR24X10061		Gasket Door Ff Wh		Appelez-nous	-
106	WR22X10013		Door Dairy		Appelez-nous	-
108	WR77X10038		Door Inner Ff		Appelez-nous	-
109	WR71X10324		Shelf Module Fixed Ff		Appelez-nous	-
115	WR71X10323		Shelf Module Ff		Appelez-nous	-
151	WR1X1554		Scr 8-18 Ab Ihxw 1/2 S		Appelez-nous	-
152	WR01A01241		Scr 8-18 Ab Fltr 5/8 S   (Replaces: WR01X10038)				$ 3.57
181	WR01X10215		Scr 10-32 Tt Hxw 3/4 S		Appelez-nous	-
910	WR78X10411		Door Foam Asm Ff Wh		Appelez-nous	-
911	WR01X10201		Thimble Top Closed		Appelez-nous	-
