SELECT A DIAGRAM

1 - Freezer Door


2 - Fresh Food Door


3 - Freezer Section


4 - Freezer Shelves


5 - Ice Maker & Dispenser


6 - Fresh Food Section


7 - Fresh Food Shelves


8 - Sealed System & Mother Board


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
6	WR12X10424		Tail Handle Sxs Bq		Appelez-nous	-
6	WR12X10203		Tail Handle Sxs Bk		Appelez-nous	-
6	WR12X10207		Tail Handle Sxs Wh		Appelez-nous	-
7	WR12X10821		Handle Sxs Wh		Appelez-nous	-
7	WR12X10819		Handle Sxs Bq		Appelez-nous	-
7	WR12X10820		Handle Sxs Bk		Appelez-nous	-
17	WR02X11474		Plate Door Stop Ff		Appelez-nous	-
17	WR02X11465		Plate Door Stop Ff		Appelez-nous	-
17	WR02X11430		Plate Door Stop Ff		Appelez-nous	-
18	WG03L01095		Cam & Thimble Fz   (Replaces: WR02X11479)				$ 6.09
103	WR24X10132		Gasket D00r Ff		Appelez-nous	-
103	WR24X10128		Gasket Door Ff		Appelez-nous	-
106	WR22X10057		Door Dairy		Appelez-nous	-
109	WR71X10728		Shelf Module Fixed Ff		Appelez-nous	-
115	WR71X10727		Shelf Module Ff		Appelez-nous	-
152	WR01X10596		Scr 8-18 Ab Fltr 5/8 S		Appelez-nous	-
181	WR01X10655		Scr 10-32 F Hxw 3/4 S		Appelez-nous	-
910	WR78X11709		Door Asm Foam Ff Bq		Appelez-nous	-
910	WR78X11645		Door Asm Foam Ff Wh		Appelez-nous	-
910	WR78X11701		Door Asm Foam Ff Bk		Appelez-nous	-
911	WR01X10201		Thimble Top Closed		Appelez-nous	-
