| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 4 | 5303305677 | Dryer-filter (Replaces: 216987501) |
|
Immediately | $ 35.19 | ||||
| 22 | 242037701 | Clip-compressor Mtg (Replaces: 216056401) |
|
$ 3.15 | |||||
| 27 | 216498900 | Grommet,compressor (Replaces: 5308002681) |
|
$ 14.46 | |||||
| 28 | 5304464023 | Support,compressor |
|
- | |||||
| 30 | 216954213 | Controller |
|
$ 44.04 | |||||
| 32 | 216954300 | Clip,controller |
|
$ 18.90 | |||||
| 42 | 216232701 | Washer,flat |
|
$ 2.10 | |||||
| 47 | 216629601 | Screw,hex Washer Head ,10-16 X 0.500 ,tapping |
|
$ 14.46 | |||||
| 55 | 297286812 | Capacitor-run,250 Va ,12 Mf (Replaces: 297286802) |
|
Immediately | $ 13.09 | ||||
| 86 | 216036601 | Screw,rwhd ,8-32a X 0.500 ,gx-ca |
|
$ 15.17 | |||||
| 43A | 5303212614 | Clip,harness Mount |
|
$ 3.20 | |||||
| F1 | 5300300173 | Condenser |
|
- | |||||
| F29 | 297068206 | Compressor,w/grommets ,w/o Electricals |
|
- | |||||
| F5 | 216987303 | Harness-main |
|
$ 95.24 | |||||
| NI | 297102800 | Spacer-tube |
|
- |
