| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | W10139562 | Freezer Door (includes Item 8 And Dispenser Front Parts) (stainless Vcm) |
|
- | |||||
| 2 | 2254608S | Handle |
|
- | |||||
| 3 | WP2182181 | Thimble, Top (Replaces: 2308091) |
|
$ 7.34 | |||||
| 4 | W11366418 | Screw (Replaces: W10114271) |
|
Immediately | $ 17.41 | ||||
| 5 | WPW10170540 | Stud, Handle (Replaces: 2219698) |
|
Immediately | $ 9.12 | ||||
| 6 | WP2171157 | Trivet (4) (Replaces: W10154867) |
|
$ 57.33 | |||||
| 7 | W10029760 | Screw |
|
- | |||||
| 8 | W10136735 | Door Gasket, Magnetic (Replaces: 2327164) |
|
$ 298.16 | |||||
| 9 | WPW10307490 | Trim, Door Shelf (Replaces: 2209681) |
|
Immediately | $ 21.84 | ||||
| 10 | WP2182179 | Door Closer, Upper Cam (Replaces: 2182179) |
|
Immediately | $ 6.80 | ||||
| 11 | WP489483 | Screw (Replaces: W10029750) |
|
$ 10.27 | |||||
| 12 | WP2206629B | Bracket, Door Stop (Replaces: 2206629) |
|
$ 38.51 | |||||
| 13 | W10029730 | Screw |
|
- |
