03 - Control Panel,door,misc.


04 - Wiring Diagram


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
6	5304521572		Control Assembly, Stainless, Complete				$ 454.35
7	5304521573		Frame, Control Panel				$ 183.95
8	5304491499		Panel, Control Mount, Bracket				$ 92.14
9	5304504070		Pc Board, Main, Control/power				$ 367.76
10	5304504071		Door Assembly, Stainless, W/pcb				$ 1,091.41
11	5304521574		Panel Assembly, Outer Door, Stainless				$ 439.40
12	5304488350		Panel, Inner Door				$ 282.79
13	5304513453		Frame, Choke Cover, Inner Door   (Replaces: 5304488351)				$ 58.64
14	5304525298		Latch, Door   (Replaces: 5304509432)			Immediately	$ 13.78
15	5304521953		Spring, Door Latch   (Replaces: 5304464069)				$ 8.03
16	5304499873		Frame, Display Board, Cover				$ 67.33
17	5304521575		Handle Assembly, Door, Stainless				$ 269.94
18	5304504072		Pc Board, Display/input			Immediately	$ 327.60
66	5304523266		Rack, Round, Wire, 3-leg   (Replaces: 5304499601)				$ 89.96
67	5304488392		Shelf, Wire				$ 263.47
