SELECT A DIAGRAM

Washer/dryer Combo


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
2222	WH01X27887		Inner Door Frame				$ 17.07
2222	WH01X27858		Washer		Appelez-nous	-
2222	WH01X27869		Pressure Switch				$ 21.87
2222	WH01X27882		Door Lock				$ 45.85
2222	WH01X27860		Fan - Blower				$ 36.49
2222	WH01X27894		Outer Door Frame				$ 47.03
2222	WH01X27872		External Drain Hose				$ 16.44
2222	WH01X27851		Door Handle		Appelez-nous	-
2222	WH01X27888		Tub Bearing		Appelez-nous	-
2222	WH01X27854		Door Cover				$ 15.30
2222	WH01X27878		Thermostat - Heater				$ 32.55
2222	WH01X27910		Hose - (assy)				$ 35.19
2222	WH01X27895		Ring Gasket		Appelez-nous	-
2222	WH01X27863		Hot Water Valve				$ 41.96
2222	WH01X27864		Heater Elemnent				$ 56.91
2222	WH01X27896		Cold Water Valve				$ 78.21
2222	WH01X27857		Thermal Cut-out Cable		Appelez-nous	-
2222	WH01X27859		Door Hinge		Appelez-nous	-
2222	WH01X27862		Manifold - Blower		Appelez-nous	-
2222	WH01X27880		Condenser Tank Gasket		Appelez-nous	-
2222	WH01X27848		Tub Holder Spring				$ 7.82
2222	WH01X27867		Axle Door Latch		Appelez-nous	-
2222	WH01X27877		Motor				$ 134.72
2222	WH01X27881		Spring Manifold		Appelez-nous	-

    View Diagram in Separate Window       Print Part List
