SELECT A DIAGRAM
01 - Section
02 - Section
New Model Search:
| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 318586 | Medallion |
|
- | |||||
| 2 | 318872 | Bracket-terminal Block |
|
- | |||||
| 3 | 299632 | Screw 7-32x5/16`` |
|
- | |||||
| 4 | 330031 | Terminal Block W/wires (Replaces: 318960) |
|
Immediately | $ 17.93 | ||||
| 5 | 325504 | 8`` Surface Element |
|
- | |||||
| 6 | 325508 | 6`` Surface Element |
|
- | |||||
| 7 | WPW10196406 | 6`` Burner Bowl (Replaces: 296481) |
|
Immediately | $ 12.05 | ||||
| 8 | WPW10196405 | 8`` Burner Bowl (Replaces: 304969) |
|
Immediately | $ 15.56 | ||||
| 9 | 328201 | Infinite Knob |
|
- | |||||
| 10 | 70655 | Screw 8-32x1/4`` |
|
- | |||||
| 11 | 312604 | Washer |
|
- | |||||
| 12 | 233161 | Indicator Light Lens |
|
- | |||||
| 13 | 334833 | Main Top (chrome) |
|
- | |||||
| 13 | 334834 | Main Top (almond) |
|
- | |||||
| 14 | 280157 | Control Seal |
|
$ 275.75 | |||||
| 15 | 288814 | Indicator Light |
|
- | |||||
| 16 | 320945 | Infinite Control (left) |
|
- | |||||
| 16 | 5500-200 | Infinite Control (right) (Replaces: 320946) |
|
Immediately | $ 54.85 | ||||
| 17 | 295850 | Screw 10 - 32 X 7/16`` |
|
- | |||||
| 18 | 334221 | Barrier |
|
- | |||||
| 19 | 334213 | Burner Box |
|
- | |||||
| 20 | 334224 | Retainer Clip |
|
- | |||||
| 21 | 299271 | Screw 10-32x1`` |
|
- | |||||
| 22 | 326974 | Screw 10abx1/2`` |
|
- | |||||
| 23 | 334222 | Harness Conduit Asm. |
|
- | |||||
| 24 | 294983 | Plate (for Key 23) |
|
- | |||||
| 25 | 110340 | Nut (for Key 23) |
|
- | |||||
| 26 | 334663 | Operating Guide |
|
- | |||||
| 26 | 334665 | Repair Parts List |
|
- | |||||
| 26 | 313191 | Screw 10-32x7/16`` |
|
- | |||||
| 26 | 335247 | Wire Harness-main |
|
- | |||||
| 26 | 334248 | Wire Harness-element |
|
- | |||||
| 26 | 334662 | Installation Guide |
|
- |
