SELECT A DIAGRAM

01 - Cabinet Back


02 - Compressor


03 - Controls


04 - Evaporator Area & Rollers


05 - Freezer Door


06 - Interior Cabinet & Freezer Shelving


07 - Optional Ice Maker Kit Ic11b P1328003w


08 - Refrigerator Door


09 - Refrigerator Shelving


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	WPW10568041		Frame, Crisper   (Replaces: 67001056)			Immediately	$ 157.90
2	WPW10671238		Rail, Center Crisper   (Replaces: 67001057)			Immediately	$ 118.46
3	WP67002633		Pan, Crisper   (Replaces: 67001315)			Immediately	$ 173.29
4	67001764		Shelf, Cantilever		Appelez-nous	-
5	67001790		Shelf Assy., Deli		Appelez-nous	-
6	67001790		Shelf Assy., Deli		Appelez-nous	-
7	W11233072		Screw   (Replaces: M0214931)			Immediately	$ 14.72
8	67001771		Pan, Snack		Appelez-nous	-
9	67001768		Seal, Rear Crisper				$ 9.45
10	67001791		Handle, Deli Pan		Appelez-nous	-
11	67001787		Extr, Front Crisper		Appelez-nous	-
11	67001789		Trim, Crisper Pan		Appelez-nous	-
12	WP67005864		Slide, Humidity Control   (Replaces: Y67001287)			Immediately	$ 8.20
13	67001063		Seal, Front Crisper				$ 38.97
14	WP12227303WD		Brace, Crisper E-ct   (Replaces: 67001059)				$ 111.25
15	WP67006878		Glass, Crisper   (Replaces: 67001060)			Immediately	$ 223.47
16	67001769		Slide Pan Rh		Appelez-nous	-
17	67001770		Slide Pan Lh		Appelez-nous	-
18	67001788		Crisper Assy		Appelez-nous	-

    View Diagram in Separate Window       Print Part List
