SELECT A DIAGRAM

01 - Cabinet Back


02 - Cabinet Bottom


03 - Cabinet Shelving


04 - Cabinet Shelving


05 - Compressor Compartment


06 - Control Assy


07 - Divider Block


08 - Evap Assy


09 - Fz Door


10 - Ref Door


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	WPW10348409		Screw   (Replaces: M0221718)			Immediately	$ 8.20
2	10253526		Assy, Ref Hndl-blk		Appelez-nous	-
3	10202001		Clip, Retainer		Appelez-nous	-
4	M0310308		Plug, Button (wht)		Appelez-nous	-
5	10961001		Bushing, Door (wht)		Appelez-nous	-
6	WP67001130		Plug, Top Hinge Button (wht)   (Replaces: M0310729)			Immediately	$ 5.98
7	10423917		Retainer-package		Appelez-nous	-
8	10423911		Retainer, Pkg		Appelez-nous	-
9	10925404W		Ass`y, Ref Door (white)		Appelez-nous	-
10	WP12550109Q		Gasket,ref Dr(white)   (Replaces: 10456801)			Immediately	$ 322.33
11	10903901		Liner, Ref Door		Appelez-nous	-
12	10418502		Door, Dairy		Appelez-nous	-
13	10310901		Tray, Butter		Appelez-nous	-
14	WP67006715		Screw   (Replaces: M0233847)				$ 7.55
15	10462801		Cover, Hinge Lower (black)		Appelez-nous	-
17	W11708403		Stop-black Door   (Replaces: 10447103)			Immediately	$ 14.75
18	10447904		Shim Hinge		Appelez-nous	-
19	10433209		Hinge, Bottom Black		Appelez-nous	-
20	M0219730		Screw				$ 7.65
21	67007018		Pin, Hinge (btm)   (Replaces: 10200801)			Immediately	$ 8.62
22	WPW10348409		Screw, Mounting   (Replaces: M0211533)			Immediately	$ 8.20
25	10201810		Cover, Handle Screw-blk		Appelez-nous	-
26	10926101		Clip, Retaining		Appelez-nous	-
27	10419101		Retainer, Ref Door		Appelez-nous	-
28	10183966		Trim, Door Shelf		Appelez-nous	-

    View Diagram in Separate Window       Print Part List
