| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 40A15 | Bulb, Light (40 Watt) (Replaces: A0282803) |
|
Immediately | $ 1.98 | ||||
| 2 | 10435512 | Frame, Ref Top Brk |
|
- | |||||
| 3 | 10931701 | Cover, Deli Bleed |
|
- | |||||
| 4 | B8386613 | Gasket |
|
- | |||||
| 5 | 10433344 | L Center Mull-pnt |
|
- | |||||
| 6 | 10685502 | Gasket, Sealing |
|
- | |||||
| 7 | 10508701 | Shield, Refrig. Light |
|
- | |||||
| 8 | 10435913 | Tray, Drip |
|
- | |||||
| 9 | 10543602 | Heater, Mullion |
|
- | |||||
| 10 | 10995002 | Freezer Bottom |
|
- | |||||
| 11 | 10779602 | Insul. Air Duct |
|
- | |||||
| 12 | D7714406 | Socket, Angle |
|
- | |||||
| 13 | 10594901 | Gasket, Mk Air Supply |
|
- | |||||
| 14 | 10996101 | Block-drain |
|
- | |||||
| 15 | 12035202 | Ref Top- E Ct |
|
- | |||||
| 16 | 10573504 | Harness, Mullion |
|
- | |||||
| 17 | R9800670 | Kit, Screw (Replaces: M0226331) |
|
$ 10.58 | |||||
| 18 | 10450822 | Membrane, Breaker |
|
- | |||||
| 19 | WP90767 | Screw (Replaces: M0216716) |
|
Immediately | $ 8.25 | ||||
| 20 | 10772301 | Insulation |
|
- | |||||
| 21 | Y00000000 | See Note Control Assembly -- (see Pages 24 And 25 For Parts Breakdown) |
|
- | |||||
| 22 | WP98165 | Screw, Sm (Replaces: M0211018) |
|
$ 8.57 | |||||
| 23 | 10440404 | Duct, Frz Air |
|
- | |||||
| 24 | M0211520 | Screw - Sm |
|
- | |||||
| 25 | 10433611 | Plate, Center Tap |
|
- | |||||
| 26 | B0523584 | Insulation Per Ft. |
|
- | |||||
| 27 | M0253916 | Screw |
|
- | |||||
| 28 | B5759626 | Gasket, Sealing |
|
- | |||||
| 29 | 10476401 | Insert-drain Blk |
|
- | |||||
| 30 | 10453001 | Cap, Switch |
|
- | |||||
| 31 | 10565401 | Knob, Control |
|
- | |||||
| 32 | WP489464 | Screw (Replaces: M0211217) |
|
Immediately | $ 8.38 | ||||
| 33 | M0224128 | Screw |
|
- | |||||
| 34 | 10995201 | Insert-mk Air Sply |
|
- | |||||
| 35 | WP489399 | Screw (Replaces: M0232903) |
|
$ 7.30 |
