SELECT A DIAGRAM

01 - Control Panel Parts


02 - Cabinet And Air Flow Parts


03 - Interior And Ventilation Parts


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	DE61-00115A		Bracket, Capacitor				$ 20.00
2	2501-001011		Capacitor			Immediately	$ 82.41
3	DE91-70063D		Diode, H.v.			Immediately	$ 17.65
4	555555		Motor Fan   (Replaces: DE31-10177E)				$ 168.82
5	DE31-90051A		Blade-fan				$ 7.72
6	DE63-00141A		Guide, Suction		Appelez-nous	-
7	DE96-00400B		Filter, Noise				$ 92.97
8	DE61-00732C		Plate, Bottom (white)		Appelez-nous	-
8	DE61-00732B		Plate, Bottom (black, Ss Model)		Appelez-nous	-
9	DE61-00407B		Reflector, Lamp		Appelez-nous	-
10	DE63-00137C		Holder, Glass (white)				$ 10.91
10	DE63-00137B		Holder, Glass (black, Ss Model)				$ 28.25
11	DE64-00911A		Glass, Lamp				$ 20.00
12	4713-001165		Lamp-halogen			Immediately	$ 37.00
13	555555		Holder, Lamp   (Replaces: DE47-00019A)				$ 168.82
14	DE66-90106B		Lever, Switch				$ 19.53
15	3405-001033		Switch-micro			Immediately	$ 19.53
16	3405-001034		Switch, Micro			Immediately	$ 16.50
17	DE66-00084B		Latch Board   (Replaces: DE66-00084A)				$ 45.53
18	DE63-00008F		Cushion-sponge		Appelez-nous	-
19	DE61-00415A		Plate, Base		Appelez-nous	-
20	555555		Sw-thermo   (Replaces: DE47-20059A)				$ 168.82
21	DE47-20034A		Thermostat (2)			Immediately	$ 22.32
22	DE26-00082D		Transformer, H.v.				$ 199.29
23	DE61-00411A		Bracket-duct Rear		Appelez-nous	-
24	W10126785		Magnetron		Appelez-nous	-
25	555555		Thermostat   (Replaces: DE47-20007A)				$ 168.82
26	DE63-00138A		Cover-front		Appelez-nous	-
27	555555		Motor, Turntable   (Replaces: DE31-10172A)				$ 168.82
28	DE61-00375A		Hook, Rack				$ 19.53
29	DE67-00179A		Coupler			Immediately	$ 25.88
30	DE97-00369A		Rack, Wire				$ 114.29
31	DE97-00368A		Ring, Roller			Immediately	$ 39.06
32	DE74-20002A		Tray-cooking				$ 120.31
33	DE71-60121A		Cover-stirrer				$ 18.69
34	DE66-20095B		Button-lock				$ 19.53
35	DE66-00167A		Blade, Stirrer		Appelez-nous	-
36	DE31-10173A		Motor-drive				$ 60.97
37	DE63-00196A		Filter, Grease			Immediately	$ 16.41

    View Diagram in Separate Window       Print Part List
