Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	DE61-00115A		Bracket, Capacitor				$ 20.00
2	2501-001035		Capacitor			Immediately	$ 113.23
3	DE91-70063D		Diode, H.v.			Immediately	$ 17.65
4	555555		Motor Fan   (Replaces: DE31-10177E)				$ 168.82
5	DE31-90051A		Blade-fan				$ 7.72
6	DE63-00141A		Guide, Suction		Appelez-nous	-
7	W10182040		Filter, Noise				$ 42.08
8	W10192477		Plate, Bottom (black)				$ 34.71
8	W10192097		Plate, Bottom (white)		Appelez-nous	-
8	DE61-00406B		Plate, Bottom (stainless)				$ 103.96
9	DE61-00407C		Reflector, Lamp				$ 10.11
10	DE63-00137A		Holder, Glass				$ 34.10
11	DE64-00911A		Glass, Lamp				$ 20.00
12	4713-001165		Lamp-halogen			Immediately	$ 37.00
13	DE47-00032B		Holder, Lamp				$ 38.34
14	DE66-90106B		Lever, Switch				$ 19.53
15	3405-001033		Switch-micro			Immediately	$ 19.53
16	3405-001034		Switch, Micro			Immediately	$ 16.50
17	DE66-00168A		Latch Board			Immediately	$ 20.72
18	DE63-00008F		Cushion-sponge		Appelez-nous	-
19	W10187747		Plate, Base		Appelez-nous	-
20	555555		Sw-thermo   (Replaces: DE47-20059A)				$ 168.82
21	DE47-20034A		Thermostat (2)			Immediately	$ 22.32
22	W10261240		Transformer, H.v.				$ 489.69
23	DE61-00411A		Bracket-duct Rear		Appelez-nous	-
24	WPW10126786		Magnetron   (Replaces: W10126786)				$ 347.05
25	555555		Thermostat   (Replaces: DE47-20007A)				$ 168.82
26	DE63-00138A		Cover-front		Appelez-nous	-
27	555555		Motor, Turntable   (Replaces: DE31-00040A)				$ 168.82
28	DE61-00375A		Hook, Rack				$ 19.53
29	DE67-00215A		Coupler, Glider		Appelez-nous	-
30	W10182049		Rack, Wire		Appelez-nous	-
31	DE61-00855A		Guide-tray		Appelez-nous	-
32	DE63-00383A		Tray-cooking				$ 146.43
33	DE71-60121A		Cover-stirrer				$ 18.69
34	DE66-20095B		Button-lock				$ 19.53
35	DE97-00631A		Stirrer, Assembly		Appelez-nous	-
36	DE31-10173A		Motor-drive				$ 60.97
37	6802A		Filter, Air   (Replaces: W10187748)			Immediately	$ 32.18
