| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 2195975 | Assembly, Frame |
|
$ 84.01 | |||||
| 2 | 2301025 | Knob, Humidity Control |
|
$ 74.39 | |||||
| 3 | 2301026 | Slide, Humidity Control |
|
- | |||||
| 4 | 2301117 | Gasket, Side |
|
$ 143.37 | |||||
| 5 | 2301568 | Cover, Meat Pan |
|
- | |||||
| 6 | W11497323 | Snack Pan (Replaces: W10142718) |
|
$ 234.84 | |||||
| 7 | 2301549 | Glide Assembly (left Hand) |
|
$ 123.81 | |||||
| 7 | 2301548 | Glide Assembly (right Hand) |
|
$ 224.83 | |||||
| 8 | 2301010 | Glide Assembly (cover, Meat) |
|
- | |||||
| 9 | 2301567 | Assembly, Pan Cover |
|
$ 237.90 | |||||
| 10 | 2301009 | Cover, Crisper |
|
$ 139.09 | |||||
| 11 | WP1125528 | Gasket, Front (Replaces: 2301116) |
|
$ 161.69 | |||||
| 12 | 2301115 | Gasket, Rear |
|
- | |||||
| 16 | W10916292 | Assembly, Crisper Pan (Replaces: 2301031) |
|
$ 209.16 | |||||
| 17 | W10165656 | Meat Pan |
|
$ 58.64 | |||||
| 18 | 2301001 | Window, Crisper Pan |
|
$ 75.59 | |||||
| 20 | 2301126 | Deflector |
|
- | |||||
| 21 | 2301017 | Cap, Crisper Pan (left Hand) |
|
- | |||||
| 21 | 2301016 | Cap, Crisper Pan (right Hand) |
|
- | |||||
| 22 | 2301227 | Window, Meat Pan |
|
- | |||||
| 24 | WPW10141748 | Shelf (Replaces: W10141748) |
|
$ 357.65 | |||||
| 25 | W11223328 | Assembly, Shelf Stud (Replaces: W10173126) |
|
Immediately | $ 14.77 | ||||
| 26 | W10141750 | Assembly, Pan Shelf |
|
$ 206.22 | |||||
| 27 | WP3-24004-109 | Screw (Replaces: W10191954) |
|
$ 9.14 | |||||
| 28 | W11527119 | Assembly, Shelf Stud (Replaces: W10173127) |
|
- | |||||
| 29 | W10191952 | Screw |
|
$ 5.65 | |||||
| 30 | WP2179243 | Trim, Handle (Replaces: 2179243) |
|
$ 109.65 |
