SELECT A DIAGRAM

1 - Freezer Door


2 - Fresh Food Door


3 - Freezer Section


4 - Evaporator Instructions


5 - Fresh Food Section


6 - Fresh Food Shelves


7 - Unit Parts


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	31-51377		Pm Mini Manual Wiring		Appelez-nous	-
1	49-60102		Use & Care Manual		Appelez-nous	-
2	WR12X10448		Pk Handle Small Asm		Appelez-nous	-
7	WR12X10449		Handle Asm Fz		Appelez-nous	-
18	WR1X1726		Scr 10-16 Ab 3/4 Ss		Appelez-nous	-
23	WR24X10095		Gasket Door Fz Wh		Appelez-nous	-
26	WR02X10767		Stop Door		Appelez-nous	-
29	WR2X8087		Plug Button Insert Wh		Appelez-nous	-
35	WR04X10073		Lens Nameplate		Appelez-nous	-
36	WR02X10713		Cap Door Corner Wh		Appelez-nous	-
37	WR02X10715		Cap Door Corner Wh		Appelez-nous	-
38	WR02X10716		Cap Door Corner Wh		Appelez-nous	-
39	WR02X10714		Cap Door Corner Wh		Appelez-nous	-
103	WR02X10792		Cap Shelf Front Lh		Appelez-nous	-
105	WR02X10791		Cap Shelf Front Rh		Appelez-nous	-
108	WR71X10281		Shelf Front Full		Appelez-nous	-
112	WR01A00517		Plug Door Rvsbl Wh   (Replaces: WR2X8693)				$ 4.37
566	WR1X1728		Scr 10-16 1/2 Ph		Appelez-nous	-
900	WR78X10413		Door Foam Asm Fz Wh		Appelez-nous	-
921	WR02X10724		Plug Door Thimble Wh		Appelez-nous	-

    View Diagram in Separate Window       Print Part List
