SELECT A DIAGRAM

10 - Case Parts


1 - Freezer Door


2 - Machine Compartment


3 - Fresh Food Door


4 - Freezer Section


5 - Freezer Shelves


6 - Ice Maker & Dispenser


7 - Fresh Food Section


8 - Fresh Food Shelves


9 - Quick Chill


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	31-46119		Installation Instruction		Appelez-nous	-
1	31-51750		Pm Mini Manual		Appelez-nous	-
1	WH2X1211		Screw		Appelez-nous	-
1	49-60559		No Item Description		Appelez-nous	-
2	WR01X10304		Hardware Pack		Appelez-nous	-
45	WR2X8818		Retainer Recess Door		Appelez-nous	-
63	WG03A00047		Spring Recess Door   (Replaces: WR02X10585)			Immediately	$ 3.97
100	WG03F00009		Door Complete Fz Service   (Replaces: WR78X12198)				$ 1,260.34
101	WR38X10281		Collar Kit- Black		Appelez-nous	-
102	WR13X10238		Top Sxs Fz Door Hinge As		Appelez-nous	-
106	WR01X10297		Fz Bottom Hinge Bushing		Appelez-nous	-
107	WR24X10203		Gasket Door		Appelez-nous	-
108	WR71X10408		Reg Bin Asm		Appelez-nous	-
110	WG03F00341		Housing Shield Disp   (Replaces: WR17X12152)				$ 18.59
111	WG03F00291		Funnel Ice Display   (Replaces: WR17X11267)				$ 63.62
113	WR01F03637		Switch   (Replaces: WR23X10224)			Immediately	$ 17.47
114	WR02X10584		Spring Funnel		Appelez-nous	-
115	WR02X10670		Reflector Light		Appelez-nous	-
116	WR2X9561		Lamp Socket		Appelez-nous	-
117	WG03A03944		Light Dispenser   (Replaces: WR02X12208)			Immediately	$ 67.41
118	WR01L00935		Crank Door Recess   (Replaces: WR17X10706)				$ 12.71
120	WR78X12341		Clad Foam Asm Fz		Appelez-nous	-
126	WG03L01708		Handle Ss   (Replaces: WR12X10842)				$ 99.55
127	WR01F01784		Solenoid Asm   (Replaces: WR62X10055)				$ 88.99
129	WR01L03203		Grille Recess Bk   (Replaces: WR17X11655)				$ 31.76
133	WR55X10157		Disp Asm- Board / Glass		Appelez-nous	-
134	WR01X10019		Screw 6-10 Pl Flp 1/2 S		Appelez-nous	-
200	WR13X10657		Hinge Door Btm		Appelez-nous	-
