| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | W10403308 | Tech Sheet (english) |
|
- | |||||
| 1 | W10403309 | Tech Sheet (french) |
|
- | |||||
| 1 | W10399389 | Use & Care Guide |
|
- | |||||
| 1 | W10394575 | Installation Instructions |
|
- | |||||
| 1 | 9762761 | Safer Cooking Tips (english) |
|
- | |||||
| 1 | W10065852 | Safer Cooking Tips (french) |
|
- | |||||
| 1 | W10075750 | Instr, Installer |
|
- | |||||
| 1 | W10340424 | Orifice (lf,rf (inner)) |
|
$ 93.67 | |||||
| 2 | W10819958 | Orifice (lf,rf (outer)) (Replaces: W10256132) |
|
$ 97.77 | |||||
| 2 | W10791075 | Orifice (cr) (Replaces: W10282663) |
|
$ 103.68 | |||||
| 2 | W11051480 | Orifice (lr,cf,rr) (Replaces: W10364221) |
|
$ 90.69 | |||||
| 3 | WPW10364555 | Orifice Holder (lf,rf) (Replaces: W10364555) |
|
$ 113.42 | |||||
| 4 | WPW10364556 | Orifice Holder (lr,cf,rr) (Replaces: W10364556) |
|
$ 102.39 | |||||
| 4 | W10282659 | Orifice Holder (cr) |
|
$ 40.50 | |||||
| 5 | W11344501 | Grate, Burner (Replaces: W10276551) |
|
Immediately | $ 218.28 | ||||
| 6 | W10323249 | Trim, Island |
|
$ 316.14 | |||||
| 8 | W10185266 | Pad, Grate (Replaces: 8286695) |
|
Immediately | $ 15.47 | ||||
| 9 | W10276494 | Bezel |
|
$ 80.42 | |||||
| 10 | W10271524 | T-strip |
|
$ 212.34 | |||||
| 11 | W10323250 | Island, Trim Insert |
|
$ 181.79 | |||||
| 12 | W10344181 | Assembly, Keypad |
|
- | |||||
| 13 | WPW10256034 | Cap, Burner (rf,lf) (Replaces: W10256034) |
|
$ 138.19 | |||||
| 13 | WPW10364463 | Cap, Burner (cr) (Replaces: W10364463) |
|
Immediately | $ 55.85 | ||||
| 13 | WPW10256032 | Cap, Burner (rr,cf,lr) (Replaces: W10256032) |
|
Immediately | $ 88.38 | ||||
| 14 | W11106799 | Base, Burner (rf,lf) (Replaces: W10256029) |
|
Immediately | $ 89.01 | ||||
| 14 | WPW10256027 | Base, Burner (rr,cf,lr) (Replaces: W10256027) |
|
Immediately | $ 101.02 | ||||
| 14 | WPW10282515 | Base, Burner (cr) (Replaces: W10282515) |
|
Immediately | $ 149.87 | ||||
| 15 | W10256046 | Spring, Electrode (lf,lr,rf,rr,cf) |
|
$ 11.56 | |||||
| 15 | 8286863 | Spring, Electrode (cr) |
|
$ 76.92 | |||||
| 16 | W10833887 | Electrode (lf,rf,rr,cf,lr) (Replaces: W10256047) |
|
Immediately | $ 31.77 | ||||
| 16 | WPW10145991 | Electrode (cr) (Replaces: W10145991) |
|
Immediately | $ 84.47 | ||||
| 17 | WPW10145531 | Assembly, Power Supply (Replaces: W10145531) |
|
Immediately | $ 311.25 | ||||
| 18 | W10352966 | Cooktop (middle) |
|
$ 320.43 | |||||
| 18 | W10352969 | Cooktop (left) |
|
$ 335.75 | |||||
| 18 | W10352967 | Cooktop (right) |
|
$ 337.26 | |||||
| 21 | W10854967 | Electrode, Wire (Replaces: 8286725) |
|
Immediately | $ 48.38 | ||||
| 23 | W11444940 | Panel, Control (Replaces: W10295785) |
|
$ 832.56 | |||||
| 24 | W10145568 | Knob, Control Rf,lf |
|
$ 52.92 | |||||
| 28 | W10145454 | Knob, Control |
|
$ 46.94 | |||||
| 29 | 3196265 | Screw (Replaces: 3400099) |
|
- | |||||
| 33 | W11233072 | Screw (Replaces: 7101P338-60) |
|
Immediately | $ 14.72 | ||||
| 35 | WP74003976 | Screw (Replaces: 7101P500-60) |
|
$ 7.55 | |||||
| 36 | W10130760 | Bracket,console (left) |
|
$ 75.94 | |||||
| 36 | W10130759 | Bracket,console (right) |
|
$ 75.94 |
