| Diagram # |
Part Number |
|
Description |
Series |
Availability |
Ships |
Price |
Add to Cart | |
| 1 |
N/P |
|
Housing, Dispenser (not Serviced) |
|
Appelez-nous
|
- |
|
|
|
| 2 |
W11624204 |
|
Screw (Replaces: 486194) |
|
|
|
$ 14.72 |
|
|
| 3 |
W10542660 |
|
Bracket, Motor |
|
|
Immediately |
$ 93.26 |
|
|
| 4 |
2305447 |
|
Clip, Wiring |
|
Appelez-nous
|
- |
|
|
|
| 5 |
WPW10205979 |
 |
Motor, Ice Door (Replaces: W10205979) |
|
|
Immediately |
$ 107.60 |
|
|
| 6 |
WPW10504458 |
 |
Door, Ice (Replaces: W10504458) |
|
|
Immediately |
$ 25.40 |
|
|
| 7 |
W10542663 |
|
Support, Ice Door |
|
|
Immediately |
$ 84.71 |
|
|
| 8 |
WP4449745 |
 |
Screw (Replaces: 4449745) |
|
|
|
$ 7.98 |
|
|
| 9 |
WP2305235 |
 |
Assembly, Spigot (Replaces: 2305235) |
|
|
|
$ 147.07 |
|
|
| 10 |
2318017 |
|
Assembly, Separator |
|
|
|
$ 125.33 |
|
|
| 11 |
N/P |
|
Housing, Middle (not Available Order Item 12) |
|
Appelez-nous
|
- |
|
|
|
| 12 |
WPW10260622 |
 |
Assembly, Housing (Replaces: W10260622) |
|
|
|
$ 491.17 |
|
|
| 13 |
W10133603 |
 |
Water, Paddle Assembly (universal Silver) (Replaces: 2305307GN) |
|
|
Immediately |
$ 339.20 |
|
|
| 14 |
W10133603 |
|
Assembly, Ice Paddle (universal Silver) (Replaces: 2305306GN) |
|
|
Immediately |
$ 339.20 |
|
|
| 15 |
2305219 |
|
Cover, Control |
|
|
|
$ 92.99 |
|
|
| 16 |
WP2321746 |
 |
Assembly, User Interface Control Cover (Replaces: 2321746) |
|
|
Immediately |
$ 318.84 |
|
|
| 17 |
WPW10151236 |
 |
Assembly, User Interface (Replaces: W10151236) |
|
|
Immediately |
$ 518.52 |
|
|
| 18 |
W11177738 |
 |
Drip Tray Assembly (universal Silver) (Replaces: 2318062US) |
|
|
Immediately |
$ 77.29 |
|
|
| 19 |
W10222215 |
|
Assembly, Led (Replaces: 2305342) |
|
|
|
$ 154.54 |
|
|
