| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | NP | Gearcase Motor Housing (refer To Color Variation Parts Page) |
|
- | |||||
| 2 | W11130204 | Assembly, Cover (Replaces: W11089023) |
|
- | |||||
| 3 | W11130205 | Assembly, Upper Shelf (Replaces: W11039724) |
|
$ 227.34 | |||||
| 4 | W11724692 | Thermistor (Replaces: W10280385) |
|
Immediately | $ 33.60 | ||||
| 5 | W11130212 | Assembly, Lower Shelf (Replaces: W11039725) |
|
$ 227.34 | |||||
| 6 | WPW10322649 | Pan, Freezer Lower (includes Items 7 & 8) (Replaces: W10322649) |
|
$ 148.25 | |||||
| 7 | W11164152 | Roller, Pan (Replaces: W10628713) |
|
Immediately | $ 15.74 | ||||
| 8 | W11175807 | Axle, Roller (Replaces: W10628712) |
|
Immediately | $ 17.90 | ||||
| 9 | WPW10119935 | Socket, Light (Replaces: 2155597) |
|
$ 106.16 | |||||
| 10 | W11396033 | Switch, Light (Replaces: W10847849) |
|
Immediately | $ 37.30 | ||||
| 11 | 4387478 | Socket, Light (Replaces: 2162085) |
|
Immediately | $ 115.67 | ||||
| 12 | W11216993 | Lamp, Led (Replaces: W11125625) |
|
Immediately | $ 43.24 | ||||
| 13 | WPW10322653 | Pan, Freezer Upper (includes Items 7 & 8) (Replaces: W10322653) |
|
$ 149.69 | |||||
| 14 | WPW10425252 | Cover, Thermistor (Replaces: W10425252) |
|
Immediately | $ 88.38 | ||||
| 15 | W11130215 | Lens (Replaces: W11050578) |
|
- |
