BB20VE (BOM: P1321301W E) | Leon's : Appliance Model Lookup

Diagram #	Part Number	Description	Availability	Ships	Price
113	WPM0104106	Clip (Replaces: M0104106)			$ 8.17
115	M0311703	Plug, Button (blk)	Appelez-nous	-
118	M0270538	Washer	Appelez-nous	-
121	12077308	Hinge, Rh Top-e Ct	Appelez-nous	-
141	B8345401	Gasket, Damper	Appelez-nous	-
144	12028502	Closure, Door (blk)	Appelez-nous	-
151	10562201	Shim, Center Hinge	Appelez-nous	-
155	12056201	Shield, Ref Light Sw	Appelez-nous	-
156	12056301	Cover, Ref Light	Appelez-nous	-
160	WP22002933	Screw, Sm (Replaces: M0211357)			$ 8.06
161	10562202	Shim, Center Hinge	Appelez-nous	-
165	W11384469	Switch, Light (Replaces: C3680310)		Immediately	$ 39.09
171	10562203	Shim, Center Hinge	Appelez-nous	-
181	10351002	Pin, Hinge (ctr)	Appelez-nous	-
186	M0270508	Washer	Appelez-nous	-
191	10561602	Pin, Door Hinge	Appelez-nous	-
201	C8902601	Insert, Control	Appelez-nous	-
211	Y00000000	See Note Use 12446512 Ctr-hinge-bk Ect, Except On The Following (m4) S/n 9912182860 Thru 3384 Which Uses Ctr-hinge Bk Ect Part No. 12446504.	Appelez-nous	-
231	D7795826	Knob, Control (wht)	Appelez-nous	-
261	R0161050	Damper Control Kit			$ 120.41
321	12045401	Cover-ref Cont	Appelez-nous	-
331	12060101	Insul, Damper	Appelez-nous	-
381	WP98165	Screw, Sm (Replaces: M0211018)			$ 8.57
401	W11573362	Screw, T. F. (Replaces: M0226233)			$ 14.72
411	67006425	Screw, Sm (Replaces: M0238616)		Immediately	$ 7.30
471	10448501	Shim, Top Hinge	Appelez-nous	-
481	10448502	Shim, Top Hinge	Appelez-nous	-
491	10448503	Shim, Top Hinge	Appelez-nous	-
601	R9800670	Screw, Tf (Replaces: M0238731)			$ 10.58
611	WP8281227	Screw, Tc (Replaces: M0220432)			$ 10.96
631	10391302	Support, Pin	Appelez-nous	-
651	12113302	Closure, Door (blk)	Appelez-nous	-
841	10493302	Cover, Frz Light	Appelez-nous	-
851	M0238846	Screw-sm	Appelez-nous	-
861	WP12246608	Plug, Top Hinge Button (blk) (Replaces: M0310731)		Immediately	$ 8.15
