SELECT A DIAGRAM

01 - Cabinet, Literature


02 - Refrigerator Liner


03 - Control


04 - Refrigerator Shelf


05 - Motor And Ice Container


06 - Refrigerator Door


07 - Freezer Door


08 - Dispenser Front


09 - Unit


10 - Freezer Liner


11 - Air Flow


12 - Ice Maker, Optional


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	2214427T		Freezer Door (includes No.8 And Dispenser Front Parts) (biscuit)		Appelez-nous	-
2	2217185T		Handle, Center (biscuit)		Appelez-nous	-
3	2217191T		Extension, Handle (biscuit)		Appelez-nous	-
4	WP489491		Screw   (Replaces: 489491)				$ 7.30
5	WP3400012		Screw   (Replaces: 3400012)				$ 8.26
7	2171071		Shelf Bin (4)		Appelez-nous	-
8	2159072		Door, Gasket Magnetic   (Replaces: 2221301)				$ 323.60
9	2217186T		Extension, Handle (biscuit)		Appelez-nous	-
10	WPW10307490		Trim, Door Shelf   (Replaces: 2209680)			Immediately	$ 24.27
12	WP489128		Screw   (Replaces: 488500)				$ 11.40
13	2187324		Wire Harness		Appelez-nous	-
14	WP2182179		Door Closer, Upper Cam   (Replaces: 2182179)			Immediately	$ 6.39
15	WP2154473		Connector   (Replaces: 2162412)				$ 24.83
16	WP489483		Screw   (Replaces: 489420)				$ 11.41
17	2200082		Bracket, Door Stop				$ 5.83
18	WP2195327		Clip   (Replaces: 2195327)				$ 7.77
20	WP3400852		Screw   (Replaces: 3400852)				$ 10.33

    View Diagram in Separate Window       Print Part List
