01 - Cooktop, Burner And Grate Parts


02 - Burner Box, Gas Valves, And Switches


03 - Optional Parts


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	W10250473		Tray, Grill Drip				$ 224.39
2	7101P436-60		Screw		Appelez-nous	-
3	WP9759091		Regulator, Pressure   (Replaces: 9759091)			Immediately	$ 340.43
4	W10189107		Bracket, Valve		Appelez-nous	-
5	W10269564		Deflector, Grill				$ 173.90
6	W10223569		Burner, Grill				$ 258.87
7	W10160154		Manifold		Appelez-nous	-
8	WPW10371235		Valve, Single Lf,rf   (Replaces: W10305287)			Immediately	$ 332.15
9	W10189097		Bushing, Burner Box				$ 8.00
10	W10189140		Screw, Valve Mtg				$ 6.82
12	W10250424		Burner Box		Appelez-nous	-
13	W10250475		Bracket, Grill Orifice Mounting		Appelez-nous	-
14	W10326645		Valve, Single Lr,cf,rr				$ 162.52
16	W10250474		Drip Tray Holder		Appelez-nous	-
17	W10250468		Drip Tray Router		Appelez-nous	-
18	W10115929		Bracket, Burner		Appelez-nous	-
19	4450800		Screw				$ 13.47
20	WPW10385583		Valve, Gas Center Rear   (Replaces: W10305286)			Immediately	$ 332.10
21	W10115843		Cover, Ignition		Appelez-nous	-
23	W10189177		Seal, Switch Cover				$ 10.00
25	W10189155		Cover, Burner Box		Appelez-nous	-
26	8285790		Bracket, Mounting Orifice				$ 85.85
27	W11601369		Reignitor, Gas   (Replaces: W10116108)			Immediately	$ 88.48
28	W10250470		Drip Tray, Router 1				$ 128.77
29	W10305285		Valve, Gas Grill				$ 364.35
30	W10250462		Flame Spreader				$ 92.34
32	WPW10267890		Module, Grill   (Replaces: W10267890)				$ 471.83
33	W10250461		Bracket, Grill Ignitor		Appelez-nous	-
34	W10268770		Ignitor, Grill				$ 161.69
NI	W10280797		Tubing, Gas (center Rear)		Appelez-nous	-
NI	W10158807		Tubing, Gas Center Grill				$ 94.65
NI	W10115908		Tubing, Gas (lf,rf)		Appelez-nous	-
NI	W10115911		Tubing, Gas (lf, Rf)				$ 188.34
NI	W10115910		Tubing, Gas (lr & Cf & Rr)				$ 176.20
