Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	4335911		Grill, Grate (2)		Appelez-nous	-
2	4336913		Element, Grill (208 Volt (opt.))		Appelez-nous	-
2	4336912		Element, Grill (240 Volt)		Appelez-nous	-
3	4336252		Block, Terminal		Appelez-nous	-
4	4336259		Clip		Appelez-nous	-
5	4335907		Grill, Air Intake		Appelez-nous	-
6	4337454		Air Filter		Appelez-nous	-
7	4337002		Cooktop, Main (almond)		Appelez-nous	-
7	4336814		Cooktop, Main (chrome)		Appelez-nous	-
8	4335339		Screw, 6-20x3/8		Appelez-nous	-
9	4336807		Reflector Grid		Appelez-nous	-
10	4337017		Grease Well (right)		Appelez-nous	-
10	4337016		Grease Well (left)		Appelez-nous	-
11	4337042		Terminal		Appelez-nous	-
12	4324647		Screw 8-32x3/8		Appelez-nous	-
13	4337041		Block, Terminal		Appelez-nous	-
14	4330868		Clamp, Terminal Block		Appelez-nous	-
15	WP681414		Screw, No.10-16 X 7/16   (Replaces: 4335248)			Immediately	$ 7.62
16	4336816		End Cap (right)		Appelez-nous	-
16	4336817		End Cap (left)		Appelez-nous	-
17	4337167		Screw, No.10 X 5/8		Appelez-nous	-
18	4336955		Rear Filler (left)		Appelez-nous	-
18	4336954		Rear Filler (right)		Appelez-nous	-
19	4336706		Retainer, Insul.		Appelez-nous	-
20	4336823		Tube, Grease		Appelez-nous	-
21	4337081		Cover, Latch		Appelez-nous	-
22	4336855		Flue Duct		Appelez-nous	-
23	4337195		Limit Switch, Thermostat		Appelez-nous	-
24	4337008		Limit Switch, Blower		Appelez-nous	-
25	4328072		Screw 6-32x5/16		Appelez-nous	-
26	4323479		Screw No.8-32x1/16		Appelez-nous	-
27	4336824		Fitting, Tube		Appelez-nous	-
28	4336360		Knob, Infinite		Appelez-nous	-
29	4336574		Bezel, Knob (right Front)		Appelez-nous	-
29	4336571		Bezel, Knob (left Rear)		Appelez-nous	-
29	4336572		Bezel, Knob (right Rear)		Appelez-nous	-
29	4336573		Bezel, Knob (left Front)		Appelez-nous	-
30	4342629		Nut, Speed		Appelez-nous	-
31	4337775		Plate, Mounting		Appelez-nous	-
32	4325524		Seal, Control		Appelez-nous	-
33	5500-200		Switch, Infinite   (Replaces: 4337621)			Immediately	$ 54.85
34	4337452		Switch, Door Lock		Appelez-nous	-
35	4335252		Indicator Light		Appelez-nous	-
36	4337213		Panel, Control		Appelez-nous	-
37	4336078		Lens, Ind. Light		Appelez-nous	-
38	WP308685		Screw, No.10 X1/2   (Replaces: 4335117)			Immediately	$ 7.08
39	4336220		Rocker Switch, Blower/hi-lo		Appelez-nous	-
40	4335904		Rocker Switch, Blower/oven Light		Appelez-nous	-
41	4335881		Screw No.4-40		Appelez-nous	-
42	4337116		Micro Switch, Thermostat		Appelez-nous	-
43	4335973		Insulation		Appelez-nous	-
44	4337451		Back, Control		Appelez-nous	-
45	4336815		Bezel, Clock/oven Control		Appelez-nous	-
46	4336919		Plate, Clock/oven Control		Appelez-nous	-
48	4337194		Knob, Clock/oven Control		Appelez-nous	-
49	4337161		Hex Nut		Appelez-nous	-
50	4337210		Lens, Clock/oven Control		Appelez-nous	-
51	4343004		Control-clock/oven		Appelez-nous	-
52	4337582		Screw, No.6-32 X 5/16		Appelez-nous	-
53	4337075		Faceplate, Clock-oven Control		Appelez-nous	-
54	4335903		Nameplate		Appelez-nous	-
55	4323217		Clip		Appelez-nous	-
56	4332521		Screw No.10-32x1/2		Appelez-nous	-
57	4337543		Speed Nut		Appelez-nous	-
58	4337312		Vent Shield		Appelez-nous	-
