| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 0042316 | Broil Orifice & Tube Ki721 |
|
- | |||||
| 2 | 42322 | Spring |
|
$ 103.13 | |||||
| 3 | 41209 | Code J |
|
- | |||||
| 4 | 0042317 | Bake Orifice & Tube Ki-721 |
|
- | |||||
| 5 | 0042299 | Thermostat Harper Oak |
|
- | |||||
| 6 | Y0042183 | Indicator Light |
|
- | |||||
| 7 | 43350 | Fan Motor |
|
- | |||||
| 8 | 0042321 | Sub 42320, Orifice & Tube As. |
|
- | |||||
| 9 | 41982 | Gasket |
|
- | |||||
| 10 | 0042320 | Orifice & Tube Assy. Ki721 |
|
- | |||||
| 11 | 0042321 | Sub 42320, Orifice & Tube As. |
|
- | |||||
| 12 | Y0042345 | Inlet Manifold |
|
- | |||||
| 13 | 0042320 | Orifice & Tube Assy. Ki721 |
|
- | |||||
| 14 | 42296 | Plug Button |
|
- | |||||
| 15 | 0042301 | Pressure Regulator Ki-721 |
|
- | |||||
| 16 | Y0041776 | Screw No.10-32x5/8 |
|
- | |||||
| 17 | Y0041941 | Washer Vinyl Asb. |
|
- | |||||
| 18 | 0042318 | Valve,surface Ki-721 |
|
- | |||||
| 19 | 0041062 | Sub 42371, Manifold Casting |
|
- | |||||
| 20 | 42319 | Roller |
|
- | |||||
| 21 | Y0040943 | Control Mtg. Plate Gas E-l. |
|
- | |||||
| 22 | 0042032 | Push Switch Tab Terminals |
|
- | |||||
| 23 | 0042032 | Push Switch Tab Terminals |
|
- | |||||
| 24 | 0043699 | 5643847 W.j. |
|
- | |||||
| 25 | Y0042037 | Licon Switch Spark |
|
- | |||||
| 27 | 42466 | Bulb |
|
- | |||||
| 28 | 0041850 | Knurl Nut |
|
- | |||||
| 29 | 0042651 | Surface Knob Ki-721 |
|
- | |||||
| 30 | 0042651 | Surface Knob Ki-721 |
|
- | |||||
| 31 | 0042651 | Surface Knob Ki-721 |
|
- | |||||
| 32 | 0042651 | Surface Knob Ki-721 |
|
- | |||||
| 33 | 42642 | Collar |
|
- | |||||
| 34 | Y0042605 | Knob Clock For 3/16 Dia Stem |
|
- | |||||
| 35 | 42465 | Receptacle |
|
- | |||||
| 36 | Y0041796 | Metal Screw 6x3/8 Phil Pan Hd |
|
- | |||||
| 37 | 0042780 | Control Panel Glass Ki-721 |
|
- | |||||
| 38 | Y0042426 | Sub 54753, Clock, Auto. |
|
- | |||||
| 39 | 0041784 | Metal Screw 8x1/4 Ph Pan Hd |
|
- | |||||
| 40 | Y0041785 | Screw, No.6-32 X .250 Pan Hd Ph |
|
- | |||||
| 41 | 0042220 | Use R0709007 |
|
- | |||||
| 42 | Y0040951 | Mounting Bracket Ki-721 |
|
- |
