SELECT A DIAGRAM

01 - Cooktop


02 - Control Panel


03 - Manifold


04 - Chassis


05 - Broiler


06 - Door, Lit/optional


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	WPW10268483		Grate, Burner (4)   (Replaces: 8053458)				$ 133.35
2	8053463		Cap, Burner (large (3))				$ 43.95
2	8053466		Cap, Burner (small (1))		Appelez-nous	-
3	W11032529		Ignitor, Burner (right Front)   (Replaces: 8053720)				$ 69.90
3	W11032529		Ignitor, Burner (left Front)   (Replaces: 8053718)				$ 69.90
3	W11032529		Ignitor, Burner (right Rear)   (Replaces: 8053719)				$ 69.90
3	W11032529		Ignitor, Burner (left Rear)   (Replaces: 8053717)				$ 69.90
4	3186478		Burner, 6,500 Btu (rr)				$ 77.59
4	WP8053360		Burner, 12500 Btu (lf, Lr, Rf)   (Replaces: 8053360)				$ 96.24
5	8053363		Cooktop (almond)		Appelez-nous	-
5	8053362		Cooktop (white)		Appelez-nous	-
6	3186010		Panel, Manifold (white)		Appelez-nous	-
6	3186020		Panel, Manifold (black)		Appelez-nous	-
7	3196045		Knob, Burner (4) (black)		Appelez-nous	-
7	3196046		Knob, Burner (4) (white)		Appelez-nous	-
12	WP3195060		Hinge, Cooktop (2)   (Replaces: 3195060)			Immediately	$ 12.55
13	W11233072		Screw   (Replaces: 3196178)			Immediately	$ 14.02
14	WP3400861		Screw   (Replaces: 3400856)				$ 7.95
15	WP3196557		Screw   (Replaces: 3196557)			Immediately	$ 7.95

    View Diagram in Separate Window       Print Part List
