| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 1113311 | Panel Frame, Side (2) |
|
- | |||||
| 2 | 1113312 | Panel Frame, Top & Bottom |
|
- | |||||
| 3 | 1113313 | Back Up Panel |
|
- | |||||
| 4 | 1113324 | Bracket, Keyhole Mounting (2) |
|
- | |||||
| 5 | 1113326 | Shoulder Screw (4) |
|
- | |||||
| 6 | 489232 | Spring Washer (4) |
|
- | |||||
| 7 | WP486255 | Nut (4) (Replaces: 486255) |
|
$ 6.47 | |||||
| 8 | 489172 | Nut (8) |
|
- | |||||
| 9 | 1113422 | Top Grille Assembly |
|
- | |||||
| 10 | 1113490 | Cover, Unit |
|
- | |||||
| 11 | WP681414 | Screw (repair) (Replaces: 488908) |
|
Immediately | $ 8.47 | ||||
| 11 | W11624204 | Screw, 8 X 1/2 (Replaces: 486194) |
|
$ 14.72 | |||||
| 12 | 1113300 | Cover, Component Assembly |
|
- | |||||
| 13 | 1113317 | Brace, Panel (2) |
|
- |
