SELECT A DIAGRAM

01 - Cabinet, Literature


02 - Cabinet Trim


03 - Freezer Liner


04 - Refrigerator Liner


05 - Refrigerator Control Panel


06 - Freezer Control Panel


07 - Refrigerator Shelf


08 - Freezer Shelf


09 - Top Grille And Unit Cover


10 - Refrigerator Door


11 - Freezer Door


12 - Upper Unit


13 - Lower Unit And Tube


14 - Air Fowl And Reservoir


15 - Icemaker


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	N/A		Liner (not A Serviceable Part)		Appelez-nous	-
2	1113649		Bracket, Light		Appelez-nous	-
3	1113650		Lens		Appelez-nous	-
4	1112613		Light, Socket		Appelez-nous	-
5	WP548049		Light Bulb   (Replaces: 548049)				$ 86.35
6	538533		Support Clip, Icemaker (2)		Appelez-nous	-
7	2000193		Grommet, Screw (2)		Appelez-nous	-
8	WP681414		Screw   (Replaces: 488552)			Immediately	$ 7.85
12	W11624204		Screw   (Replaces: 486194)				$ 14.02
13	1112591		Spacer, Control Panel (3)		Appelez-nous	-
14	2215823		Clip, Air Duct (4)   (Replaces: 842534)				$ 10.42
16	1112260		Support,evaporator		Appelez-nous	-
17	2004068		Stud, Shelf (20)		Appelez-nous	-
18	487559		Screw		Appelez-nous	-
